Brand Name : | GSE |
Model Number : | PW120Z24-US016 |
Certification : | 3C |
Price : | Negotiable |
Payment Terms : | T/T |
Supply Ability : | 100 EA/day |
Delivery Time : | 15-25 working days |
GSE PW120Z24-US016 , VPSA compressor , for oxygen generator , DC24V , 123W
Product Descriptions:
A VPSA compressor (Vacuum Pressure Swing Adsorption) is a type of compressor that uses an adsorption process to compress a gas. It works by adsorbing the gas on the surface of a material, usually activated carbon, and then compressing it by applying a vacuum. The process is then repeated to obtain a higher pressure. VPSA compressors are often used in applications such as vacuum distillation, gas separation, and gas storage.
Specifications:
Model | PW120Z24-US016 |
Rated Voltage(V) | DC 24V |
Input Power(W) | ≤123W |
Rated pressure(kPa) | 62KPa/-49KPa |
Rated flow(Vaccum) | ≥29 L/min@24V @-49KPa |
Rated flow(LPM) | ≥25 L/min@24V @62KPa |
Ambient(°C) | 5-40°C |
Insulation class | B |
Net weight(Kg) | 1.28Kg |
Restart pressure(Kpa) | 0kPa |
Features:
1.VPSA
2. High performance cup seal
3. High quality bearings
4. Die-cast components
Advantages:
1. Oil-less
2. Maintainance free
3. Long life
4. Portable
![]() |
